The Quadro P620 was a professional graphics card by NVIDIA, launched on February 1st, 2018. Built on the 14 nm process, and based on the GP107 graphics processor, the card supports DirectX 12. The GP107 graphics processor is an average-sized chip with a die area of 132 mm² and 3,300 million transistors. Unlike the fully unlocked GeForce GTX 1050 Ti, which uses the same GPU but has all 768 shaders enabled, NVIDIA has disabled some shading units on the Quadro P620 to reach the product's target shader count. It features 512 shading units, 32 texture mapping units, and 16 ROPs. NVIDIA has paired 2,048 MB GDDR5 memory with the Quadro P620, which are connected using a 128-bit memory interface. The GPU is operating at a frequency of 1266 MHz, which can be boosted up to 1354 MHz, memory is running at 1252 MHz (5 Gbps effective).
Being a single-slot card, the NVIDIA Quadro P620 does not require any additional power connector, its power draw is rated at 40 W maximum. Display outputs include: 4x
